GEOTAB - Universal Heavy Duty Harness Kit — HRN-GS09K2
The HRN-GS09K2, a Deutsch T-harness kit with four mounting brackets, connects a Geotab® GO device to most international heavy-duty vehicles. The HRN-GS09K2 contains four mounting adapters, engraved with numbers for easy reference. The adapters are named as follows:
|
| ! IMPORTANT: The State of California currently prohibits Installing HRN-GS09K2 in a manner that relocates the in-vehicle diagnostic connector as described in these instructions. See HRN-GS09K2 Installation - Direct Plug-In for guidance on installing this harness using a direct plugin installation method without relocating the data link connector. Alternatively, GO devices can be installed directly into the OBDII port using an extension/conversion harness that plugs directly into the OBDII port or other emissions diagnostic data link connector port. For more information on Geotab harnesses and adapters, see Harness Identification and Application. |
Harness Technical Specifications
| Weight |
140 g |
| Size |
Max Length: 685 mm Max Width: 47.8 mm |
| Material |
Universal 9-pin connectors: Polycarbonate, Nylon, Silicone (rubber) Adapters: Polycarbonate Universal 16-pin connector: PBT Wire Jacket: Mesh Sheathing |
| Connectors |
2 × Universal Deutsch Connectors 1 × 24 V compatible ALDL Connector |
| Power Output |
8 V to 36 V |
| Current Rating |
5 A |
| Temperature Rating |
−40 to +85 °C |
| Adapters |
See Adapters Below |
